Here you will find example drawings and downloads related to our core product lines.

Precast concrete tanks

Tank Capacity ID PDF drawing
J tank 850 litres PT-J-01-231118 Download
H1.2 tank 1200 litres PT-H1.2-01-211118 Download
N tank 2200 litres PT-N-01-231118 Download
H tank 2500 litres PT-H-01-221118 Download
U tank 3050 litres Septic_U_tank_191223 Download
H+ tank 3500 litres PT-Hplus-01-211118 Download
T tank 4500 litres PT-T-01-140520 Download
S tank 6000 litres PT-S-01-201118 Download
SW tank 6000 litres PT-SW-01-201118 Download
S+ tank 7000 litres PT-Splus-01-201118 Download
S+W tank 7000 litres PT-SplusW-01-201118 Download
P3 tank 8500 litres PT-P3-01-081119 Download
P+2 tank 9000 litres PT-P+2-01-160324 Download
L tank 10000 litres PT-L-01-211118 Download
LW tank 10000 litres PT-LW-01-201118 Download
P4 tank 11300 litres PT-P4-01-081119 Download
P+3 tank 13500 litres PT-P+3-01-160324 Download
P5 tank 14170 litres PT-P5-01-081119 Download
D tank 15000 litres PT-D-01-211118 Download
P6 tank 17000 litres PT-P6-01-081119 Download
P+4 tank 18000 litres PT-P+4-01-160324 Download
O tank 18000 litres PT-O-01-081119 Download
Q tank 25000 litres PT-Q-01-081119 Download
P+6 tank 27000 litres PT-P+6-01-160324 Download
R tank 38000 litres PT-R-01-081119 Download
For additional information, refer to the precast concrete tanks product page.

Wastewater

System Type PE ID PDF drawing
450 P.E. Tailored wastewater systems 450 TS-R-007-130520 Download
200 P.E. Tailored wastewater systems 200 TS-R-005-110220 Download
100 P.E. Tailored wastewater systems 100 TS-Q-006-130520 Download
S+ septic tank with PS Septic tanks with PS NS-5 Septic_Splus tank_PS_170719 Download
S+ septic tank Septic tanks NS-5 Septic_Splus tank_140619 Download
S septic tank with PS Septic tanks with PS NS-4 Septic_S tank_PS_170719 Download
S septic tank Septic tanks NS-4 Septic_S tank_140619 Download
8PE Coco Chieftain Coco filter 8 Coco_8PE_02_211119 Download
8PE Coco Chieftain Coco filter 8 Coco_8PE_01_211119 Download
15PE Coco Chieftain Coco filter 15 Coco_15PE_02_211119 Download
15PE Coco Chieftain Coco filter 15 Coco_15PE_01_211119 Download
8 P.E. Domestic wastewater systems – pumped 8 C_SBR_8PE_P1_070420 Download
8 P.E. Domestic wastewater systems 8 C_SBR_8PE_Gravity_070420 Download
50 P.E. Packaged wastewater systems 50 C_SBR_50PE_090420 Download
41 P.E. Packaged wastewater systems 41 C_SBR_41PE_P1_090420 Download
30 P.E. Packaged wastewater systems 30 C_SBR_30PE_P1_090420 Download
24 P.E. Packaged wastewater systems 24 C_SBR_24PE_P1_090420 Download
20 P.E. Packaged wastewater systems 20 C_SBR_20PE_P1_090420 Download
17 P.E. Packaged wastewater systems 17 C_SBR_17PE_P1_070420 Download
14 P.E. Packaged wastewater systems 14 C_SBR_14PE_P1_090420 Download
12 P.E. Domestic wastewater systems – pumped 12 C_SBR_12PE_P1_070420 Download
12 P.E. Domestic wastewater systems 12 C_SBR_12PE_Gravity_070420 Download
U septic tank Septic tanks NS-3 Septic_U_tank_191223 Download
For additional information, refer to the wastewater product pages.

Pump stations

System Type Volume Effective volume ID PDF drawing
Irish Water – Sample A Tailored Pumping Stations 8.5 5.5 PS-P3-010-050320 Download
Irish Water – Sample B Tailored Pumping Stations 56 45.6 PS-P6-008-050520 Download
Bespoke PS example Tailored Pumping Stations 121 120 PS-P6-011-130520 Download
J Domestic Packaged Pumping Stations 850 600 PS-J-05-070420 Download
J Packaged Pumping Stations 850 600 PS-J-009-300420 Download
H 1.2 Domestic Packaged Pumping Stations 1200 680 PS-H1.2-01-070420 Download
H Domestic Packaged Pumping Stations 2500 1820 PS-H-01-070420 Download
H+ Packaged Pumping Stations 3500 2880 PS-Hplus-043-090320 Download
S+ Packaged Pumping Stations 7000 5440 PS-Splus-082-120520 Download
P3 Packaged Pumping Stations 8500 6000 PS-P3-013-120520 Download
L Packaged Pumping Stations 10000 7100 PS-L-063-120520 Download
2S+ Packaged Pumping Stations 14000 10880 PS-Splus-083-130520 Download
2L Packaged Pumping Stations 20000 14200 PS-L-064-130520 Download
Irish Water – Sample C Tailored Pumping Stations PS-P6-010-130520 Download
For additional information, refer to the pump stations product page.

Rainwater Harvesting

System Total capacity Useable capacity ID PDF drawing
S+ Domestic 7000 5700 RWH-Splus-110719 Download
S+ 7000 5700 RW-1Splus-GEP-001-190719 Download
L Domestic 10000 7900 RWH-L-110719 Download
L 10000 7900 RW-1L-GEP-001-190719 Download
2S+ 14000 11400 RW-2Splus-GEP-001-190719 Download
2L 20000 15800 RW-2L-GEP-001-190719 Download
Q 25000 21480 RW-Q-GEP-001-290120 Download
R 38000 33000 RW-R-GEP-001-120520 Download
2R 76000 66000 RW-2R-GEP-001-141119 Download
For additional information, refer to the rainwater harvesting product page.

Oil - Water separators

Drawing ID Nominal flow Peak flow Drainage area Silt storage capacity Oil storage capacity PDF drawing
NSB80-LD-201218 80 800 44444 8000 1500 Download
NSB70-2L-250219 70 700 38888 7000 1500 Download
NSB50-2L-150219 50 500 27777 7320 1200 Download
NSB40-2Splus-010219 40 400 22222 4850 1200 Download
NSB30-2Splus-010219 30 300 16666 4850 950 Download
NSB20-SplusHplus-010219 20 200 11111 3730 445 Download
NSB15-SplusHplus-010219 15 150 8333 3310 455 Download
NSB10-SH-010219 10 100 5555 2860 320 Download
NSB06-HH-010219 6 60 3333 1600 320 Download
NSB03-HH-130818 3 30 1666 1600 320 Download
FR_NS80_2L_220818 80 4444 8200 2400 Download
FR_NS70_2L_250219 70 3888 8200 2400 Download
FR_NS50_2C_210818 50 2777 5000 2000 Download
FR_NS40_2Splus_210818 40 2222 4000 1910 Download
FR_NS30_L_210818 30 1666 4100 1200 Download
FR_NS20_S_210818 20 1110 2170 770 Download
FR_NS15_S_210818 15 833 2170 770 Download
FR_NS100_2D_220818 100 5555 12000 3100 Download
FR_NS10_Hplus_140818 10 555 1370 460 Download
FR_NS06_H_140818 6 335 890 340 Download
FR_NS03_H_140818 3 170 890 340 Download
FC_NS10-LH-121018 10 555 1000 7600 Download
FC_NS06-LH-121018 6 335 1000 7600 Download
For additional information, refer to the oil - water separators product page.

Grease traps

System Volume ID PDF drawing
Fig.8 1450 fg-ns-4-fig8 Download
2H 5000 fg-ns-10-2h Download
2H+ 7000 fg-ns-15-2hplus Download
For additional information, refer to the grease traps product page.
